        K7-BT

Tuya Bluetooth Mini Keypad

> One relay, 1000 users (990 Normal Users + 10 Visitor Users)

> 3 access modes: Card, PIN, Card + PIN

> Card type: 125KHz EM card

> PIN length: 4~6 digits

> Anti-tamper alarm
> Waterproof, IP66
> Mini size: Diameter: 73mm, Thickness: 20mm





The K7-BT is a Bluetooth-enabled waterproof Mini RFID & Keypad access controller. It's integrated
with
Tuya which supports 100 mobile users (including 255 card/PIN users). It's available for both iOS and Anddroid.


User Capacity
Normal Users
Visitor Users
1000 Cards/PINS
990
10
Operating Voltage
Idle Current
Active Current
12~18V DC
50mA
80mA
Keypad12 Keys
Proximity Card Reader
Radio Technology
Read Range
EM
125KHz EM Card
2-4 cm
Wiring ConnectionsRelay Output, Exit Button
Relay
Adjustable Relay Output Time
Lock Output Load
One (NO, NC, Common)
0-99 Seconds (5 seconds default)
2 Amp Maximum
Environment
Operating Temperature
Operating Humidity
Outdoor (IP66)
-40°C~ 60°C (-40°F ~ 140°F)
10%RH-90%RH
Physical
Color
Dimensions
Unit Weight
Shipping Weight
Zinc-Alloy Enclosure
Silver & Black
Diameter: 73mm, Thickness: 20mm
185g
285g
